W-serie (kuglekugle type) Vandpumpe leje, W-serie kugleleje vandpumpe leje, er en højpræcision kugleleje, der er specielt designet til vandpumper. Den vedtager en struktur, hvor kugler er installeret mellem den indre stålring og den ydre stålring, som kan modstå store belastninger og samtidig sikre lav friktionsmodstand og høj driftseffektivitet. Denne form for pejling har fordelene ved lille startfriktion, passende arbejdende friktion og let start ved lav temperatur. Det er velegnet til forskellige vandpumpeudstyr, der kræver effektiv og stabil drift.
Produktparametre
| Indenlandske modeller | NSK | Fag | Dimension (tomme) | |||
|---|---|---|---|---|---|---|
| EN | B | C | D | |||
| WIB163073 | 885154 | W2289 | 2.89 | 0.16 | 1.2 | 0.6267 |
| WIB163083 | 885165 | W2325 | 3.25 | 0.16 | 1.56 | 0.6267 |
| WIB163090 | - | W2355-3 | 3.55 | 0.67 | 1.35 | 0.6267 |
| WIB163093 | 885330 | W2366 | 3.66 | 0.73 | 1.4 | 0.6267 |
| WIB163094 | - | W2371 | 3.71 | 0.69 | 1.5 | 0.6267 |
| WIB163096 | - | W2375-3 | 3.76 | 0.56 | 1.67 | 0.6267 |
| WIB163098 | 885307 | W2385 | 3.86 | 0.67 | 1.66 | 0.6267 |
| WIB1630102 | 885321 | W2401-3 | 4.02 | 0.67 | 1.82 | 0.6267 |
| WIB1630103 | 885140 | W2406-1 | 4.06 | 0.92 | 1.61 | 0.6267 |
| WIB1630105 | 885329 | W2415-1 | 4.15 | 0.8 | 1.82 | 0.6267 |
| WIB1630106 | 885097 | W2417-2 | 4.17 | 0.81 | 1.83 | 0.6267 |
| WIB1630109 | 885107b | W2431 | 4.31 | 0.58 | 2.2 | 0.6267 |
| WIB1630110 | 885332 | W2434 | 4.35 | 0.84 | 1.97 | 0.6267 |
| WIB1630110A | 885332 | W2434-1 | 4.35 | 0.84 | 1.97 | 0.6267 |
| WIB1630111 | 885528 | W2435 | 4.36 | 0.77 | 2.06 | 0.6267 |
| WIB1630112 | 885167 | W2439 | 4.39 | 0.94 | 1.92 | 0.6267 |
| WIB1630112A | 885167d | W2440-4 | 4.4 | 1.15 | 1.72 | 0.6267 |
| WIB1630112B | - | W2441-1 | 4.41 | 1.06 | 1.82 | 0.6267 |
| WIB1630114A | 885156 | W2446 | 4.47 | 1.08 | 1.86 | 0.6267 |
| WIB1630116 | 885337a | W2454 | 4.55 | 0.81 | 2.21 | 0.6267 |
| WIB1630116A | 885162 | W2456 | 4.56 | 1.1 | 1.93 | 0.6267 |
| WIB1630116B | - | W2456-1 | 4.57 | 1.07 | 1.97 | 0.6267 |
| WIB1630119 | 885118 | W2468 | 4.69 | 1.47 | 1.69 | 0.6267 |
| WIB1630119A | - | W2468-1 | 4.69 | 1.47 | 1.69 | 0.6267 |
| WIB1630120 | 885221 | W2472 | 4.72 | 1.44 | 1.75 | 0.6267 |
| WIB1630121 | 885222 | W2475 | 4.75 | 1.5 | 1.72 | 0.6267 |
| WIB1630121A | 885105 | W2476-2 | 4.76 | 1.16 | 2.07 | 0.6267 |
| WIB1630122D | 885476 | W2481 | 4.81 | 1.34 | 1.94 | 0.6267 |
| WIB1630122B | 885168C-1 | W2481-1 | 4.81 | 1.13 | 2.16 | 0.6267 |
| WIB1630123 | - | W2485 | 4.85 | 0.77 | 2.56 | 0.6267 |
| WIB1630124 | 885100b | W2486-2 | 4.87 | 1.25 | 2.09 | 0.6267 |
| WIB1630128 | 885141 | W2503 | 5.03 | 1.02 | 2.48 | 0.6267 |
| WIB1630128A | 885151b | W2503-6 | 5.03 | 1.75 | 1.75 | 0.6267 |
| WIB1630129 | 885169-1 | W2507 | 5.08 | 1.25 | 2.3 | 0.6267 |
| WIB1630135A | 885437 | W2532 | 5.33 | 2 | 1.79 | 0.6267 |
| WIB1630136A | 885158p | W2537 | 5.37 | 1.54 | 2.3 | 0.6267 |
| WIB1630139 | - | W2547 | 5.47 | 0.91 | 3.03 | 0.6267 |
| WIB1630139A | 885603 | W2548-1 | 5.49 | 1.38 | 2.58 | 0.6267 |
| WIB1630143 | 885144 | W2562 | 5.63 | 1.58 | 2.52 | 0.6267 |
| WIB1630146 | - | W2575 | 5.76 | 2.51 | 1.71 | 0.6267 |
| WIB1630146A | 885694 | W2575-2 | 5.75 | 2.43 | 1.79 | 0.6267 |
| WIB1630162 | 885117 | W2637 | 6.37 | 2.3 | 2.55 | 0.6267 |
| WIB1630102 | 885321 | W3399 | 4 | 0.69 | 1.78 | 0.6275 |
| WIB1630122 | 885168AA | W3481-5 | 4.81 | 1.58 | 1.7 | 0.6275 |
| WIB1630122A | 885168AA | W3481-6 | 4.81 | 1.58 | 1.7 | 0.6275 |
| WIB1630132 | 885521 | W3520-2 | 5.2 | 1.58 | 2.09 | 0.6275 |
| WIB1630132A | 885521 | W3520-3 | 5.2 | 1.58 | 2.09 | 0.6275 |
| WIB1630133 | 885611 | W3522-1 | 5.22 | 1.17 | 2.52 | 0.6275 |
| WIB1630154 | 885613 | W3607 | 6.07 | 1.17 | 3.37 | 0.6275 |
| WIB1630154A | 885613 | W3607-1 | 6.07 | 1.17 | 3.37 | 0.6275 |
| WIB163093OS | 885330OS | W6366 | 3.66 | 0.73 | 1.4 | 0.629 |
| WIB163098OS | 885307OS | W6385 | 3.86 | 0.67 | 1.66 | 0.629 |
| WIB1630102OS | 885321OS | W6401-3 | 4.02 | 0.67 | 1.82 | 0.629 |
| WIB1630103OS | 885140OS2 | W6406-1 | 4.06 | 0.92 | 1.61 | 0.629 |
| WIB1630105OS | 885329OS | W6415-1 | 4.15 | 0.8 | 1.82 | 0.629 |
| WIB1630109OS | 885111dos2 | W6428-1 | 4.28 | 1.08 | 1.67 | 0.629 |
| WIB1630110COS | 885524SOS2 | W6433-2 | 4.33 | 1.14 | 1.66 | 0.629 |
| WIB1630110OS | 885332OS | W6434 | 4.36 | 0.77 | 2.06 | 0.629 |
| WIB1630112OS | 885167OS2 | W6439 | 4.39 | 0.94 | 1.92 | 0.629 |
| WIB1630112AOS | 885167DOS2 | W6440-4 | 4.4 | 1.15 | 1.72 | 0.629 |
| WIB1630113OS | 885155OS | W6445 | 4.45 | 1.25 | 1.67 | 0.629 |
| WIB1630113AOS | 885156OS | W6446 | 4.47 | 1.08 | 1.86 | 0.629 |
| WIB1630114OS | 885697OS2 | W6450-2 | 4.5 | 1.26 | 1.71 | 0.629 |
| WIB1630116OS | 885337aos | W6454 | 4.55 | 0.81 | 2.21 | 0.629 |
| WIB1630116AOS | 885162OS | W6456 | 4.56 | 1.1 | 1.93 | 0.629 |
| WIB1630119OS | 885118OS2 | W6468 | 4.69 | 1.47 | 1.69 | 0.629 |
| WIB1630119BOS | 885118OS | W6468-1 | 4.69 | 1.47 | 1.69 | 0.629 |
| WIB1630119AOS | 885135SOS2 | W6470 | 4.7 | 1.28 | 1.89 | 0.629 |
| WIB1630121OS | 885105OS2 | W6476 | 4.76 | 1.16 | 2.07 | 0.629 |
| WIB1630122OS | - | W6478-1 | 4.79 | 1.24 | 2.02 | 0.629 |
| WIB1630122DOS | 885476OS2 | W6481 | 4.81 | 1.33 | 1.95 | 0.629 |
| WIB1630122BOS | 885168COS2 | W6481-1 | 4.81 | 1.13 | 2.16 | 0.629 |
| WIB1630123OS | - | W6484 | 4.84 | 1.45 | 1.86 | 0.629 |
| WIB1630124OS | 885100BOS2 | W6486-2 | 4.87 | 1.25 | 2.09 | 0.629 |
| WIB1630128OS | 885141OS2 | W6503 | 5.03 | 1.02 | 2.48 | 0.629 |
| WIB1630129OS | 885169OS2 | W6507 | 5.08 | 1.25 | 2.3 | 0.629 |
| WIB1630134OS | 885113BOS2 | W6527 | 5.27 | 1.68 | 2.06 | 0.629 |
| WIB1630136OS | 885093SOS2 | W6534-1 | 5.34 | 2.06 | 1.75 | 0.629 |
| WIB1630136AOS | 885158POS2 | W6537 | 5.37 | 1.54 | 2.3 | 0.629 |
| WIB1630138OS | 885158OS2 | W6543 | 5.44 | 1.61 | 2.3 | 0.629 |
| WIB1630139OS | 885603OS2 | W6548-1 | 5.49 | 1.38 | 2.58 | 0.629 |
| WIB1630141OS | 885248OS2 | W6555 | 5.55 | 1.93 | 2.09 | 0.629 |
| WIB1630141AOS | - | W6556 | 5.56 | 1.53 | 2.5 | 0.629 |
| WIB1630143AOS | 885144OS2 | W6562 | 5.62 | 1.58 | 2.52 | 0.629 |
| WIB1630143OS | 885144OS2 | W6562-1 | 5.62 | 1.58 | 2.52 | 0.629 |
| WIB1630146OS | 885694SOS2 | W6575-1 | 5.75 | 2.43 | 1.79 | 0.629 |
| WIB1630150OS | 885116COS2 | W6590-2 | 5.9 | 1.38 | 2.99 | 0.629 |
| WIB1630162OS | 885117OS | W6637 | 6.37 | 2.3 | 2.55 | 0.629 |
| WIB1630102OS | 885321OS2 | W7399-1 | 4 | 0.69 | 1.78 | 0.6295 |
| WIB1630122BOS | 885168HOS2 | W7481-1 | 4.81 | 1.13 | 2.16 | 0.6295 |
| WIB1630122OS | 885168aaos | W7481-6 | 4.81 | 1.58 | 1.7 | 0.6295 |
| WIB1630132OS | 885521OS2 | W7520-2 | 5.2 | 1.58 | 2.09 | 0.6295 |
| WIB1630133OS | 885611OS | W7522-1 | 5.22 | 1.17 | 2.52 | 0.6295 |
| WIB1630154OS | 885613OS | W7607-1 | 6.07 | 1.17 | 3.37 | 0.6295 |
